Xantrex 818-2015 Freedom XC Pro Marine 2000W True Sine Wave Inverter/Charger

Save $831.00
XantrexSKU: 30-3117

Price:
Sale price$2,527.00 Regular price$3,358.00

Shipping calculated at checkout

Stock:
Only 4 units left

Description

Upgrade your boat, RV, or mobile power system with the Xantrex Freedom XC Pro Marine Inverter/Charger (Part #818-2015). This brand new power system combines a 2,000-watt true sine wave inverter, powerful 100-amp multi-stage battery charger, and automatic AC transfer functionality in one compact unit designed for demanding 12V applications.

Product Details

  • The Freedom XC Pro Marine produces clean true sine wave AC power suitable for sensitive electronics and motor-driven appliances. Its 4,000-watt surge capability provides up to twice its continuous output for short-duration startup loads, helping operate equipment such as refrigerators, pumps, and other motor-driven appliances.

Features

  • Genuine Xantrex 818-2015 Freedom XC Pro Marine
  • Brand New
  • 2,000-watt continuous true sine wave output
  • Up to 4,000 watts surge output
  • Designed for 12V battery systems
  • 100-amp battery charging capability
  • Power-factor-corrected multi-stage charging
  • Built-in lithium-ion battery charging support
  • Battery equalization capability
  • Clean true sine wave AC output for sensitive electronics
  • Extended surge capability for compressor and motor startup loads
  • Automatic AC transfer functionality
  • Programmable AC under-voltage shutdown
  • Power Share functionality
  • Overload alarm and automatic shutdown protection
  • Over-temperature alarm and shutdown protection
  • Remote on/off capability
  • Ignition control capability
  • Supports CANbus / NMEA 2000 integration
  • Optional Bluetooth remote panel capability
  • Compact, lightweight design
  • Up to 91% inverter efficiency

Specifications

  • Manufacturer Part Number: 818-2015
  • Series: Freedom XC Pro Marine
  • Product Type: Inverter / Battery Charger
  • Battery System: 12 Volt
  • Continuous AC Output: 2,000 Watts
  • Peak / Surge Output: 4,000 Watts
  • Waveform: True Sine Wave
  • Charger Output: 100 Amps
  • Inverter DC Input: 10.5–15.5 Volts DC
  • Charger AC Input: 90–130 Volts AC
  • Efficiency: Up to 91%
  • Operating Temperature: 4°F to 140°F
  • Length: 15.4 Inches
  • Width: 10.8 Inches
  • Height: 4.9 Inches without flanges
  • Remote On/Off: Capable
  • Bluetooth Monitoring: Optional Remote Panel Required
  • NMEA 2000: Supported
  • Standards: ETL Listed to CSA 107.1 / UL458 / ABYC E11 / A-31
  • Charging & Power Management
  • The Freedom XC Pro Marine incorporates configurable charging and power-management features for sophisticated onboard electrical systems, including:
  • Power-factor-corrected multi-stage charging
  • Lithium-ion battery charging support
  • Battery equalization
  • Power Share
  • Programmable AC under-voltage shutdown
  • Automatic transfer between incoming AC and inverter power
  • Ignition-controlled inverter operation
  • Configurable system monitoring and control
  • The programmable AC under-voltage feature is particularly useful when operating from weak shore power or generator sources.
  • Connectivity & Monitoring
  • The Freedom XC Pro Marine supports Micro-C NMEA 2000 connectivity, allowing integration with compatible third-party marine monitoring and control systems.
  • An optional Bluetooth remote panel, sold separately, can provide additional system monitoring and configuration through a compatible Bluetooth application.

Applications

  • Ideal for 12V electrical systems requiring dependable AC power and high-output battery charging, including:
  • Boats and marine electrical systems
  • Motorhomes
  • RVs and fifth wheels
  • Camper vans
  • Off-grid power systems
  • Mobile work vehicles
  • Sensitive electronic equipment
  • Refrigerators and compressor-driven loads
  • Shore-power and generator-equipped installations

Installation Notes

  • Designed for 12V battery systems
  • Proper DC cable sizing and overcurrent protection are essential
  • Verify battery bank compatibility and charging requirements before installation
  • Ensure adequate ventilation and installation clearances
  • AC and DC wiring must be appropriately sized for the installation
  • Marine installations should follow applicable ABYC electrical standards
  • Professional installation is recommended for high-current inverter/charger systems
  • Optional remote panels and related accessories are sold separately

Warranty

  • Limited 2-Year Warranty
  • Image may differ from actual product.
