Warn 77560 Series 20XL Hydraulic Industrial Winch, 20,000 lb Long Drum Air Clutch

Save $2,433.00
WarnSKU: 13-7368

Price:
Sale price$7,401.00 Regular price$9,834.00

Shipping calculated at checkout

Stock:
Only 2 units left

Description

Take on the toughest recovery and industrial pulling applications with the WARN Series 20XL Hydraulic Winch (Part #77560). This brand new industrial-grade hydraulic winch delivers an impressive 20,000-pound line pull capacity and is engineered for severe-duty environments including trailers, rollback carriers, utility vehicles, construction equipment, and commercial applications.

Product Details

  • Powered by a high-performance 8.0 cubic inch hydraulic motor, the Series 20XL provides continuous-duty operation without the limitations of electric winches. Its hardened aircraft-grade nickel chromalloy two-stage planetary gear train delivers fast line speeds, outstanding reliability, and dependable performance under heavy loads. The integrated spring-applied disc brake securely holds the full rated load, while the air-operated clutch and long drum configuration provide exceptional versatility for professional applications.

Features

  • Genuine WARN 77560 OEM hydraulic industrial winch
  • Brand New
  • Massive 20,000 lb maximum line pull capacity
  • Heavy-duty hydraulic motor for continuous-duty operation
  • Long drum design for increased rope capacity
  • Air-operated clutch for reliable engagement and free spooling
  • Hardened aircraft-grade nickel chromalloy two-stage planetary gear train
  • Spring-applied disc brake holds the full rated load
  • Fast, efficient line speeds under heavy loads
  • Ideal for rollback carriers, trailers, industrial equipment, and severe-duty applications
  • Meets SAE J706 and CE specifications

Specifications

  • Manufacturer Part Number: 77560
  • Series: WARN Series 20XL
  • Product Type: Hydraulic Industrial Winch
  • Maximum Line Pull: 20,000 Pounds
  • Operation: Hydraulic
  • Recommended Use: Industrial
  • Mount Type: Fixed Mount
  • Drum Style: Long Drum
  • Clutch Type: Air Clutch
  • Gear Train: Two-Stage Planetary
  • Gear Ratio: 28.5:1
  • Brake Type: Spring Applied Disc
  • Hydraulic Motor: 8.0 Cubic Inch High Performance
  • Line Speed at Max Load: 28.5 Feet Per Minute
  • Mounting Pattern: 18 Inch Ɨ 7-1/2 Inch
  • Mounting Holes: 8
  • Color: Black
  • Estimated Installation Time: Approximately 2 Hours

What's Included

  • (1) WARN Series 20XL Hydraulic Winch
  • Long drum assembly
  • Air clutch mechanism
  • Not Included:
  • Wire rope or synthetic rope
  • Fairlead
  • Remote control
  • Mounting hardware

Compatibility

  • Suitable for heavy-duty industrial and commercial applications including:
  • Rollback carriers
  • Heavy equipment trailers
  • Utility trucks
  • Construction equipment
  • Industrial recovery equipment
  • Custom hydraulic winch installations
  • Please verify your mounting dimensions, hydraulic system specifications, and application requirements before ordering.

Installation Notes

  • Professional installation is recommended
  • Hydraulic plumbing must be sized appropriately for maximum winch performance
  • Rope, fairlead, and mounting hardware are sold separately
  • Verify hydraulic flow and pressure meet WARN specifications before operation
  • Inspect all mounting hardware and hydraulic connections before use

Warranty

  • Limited 1-Year Warranty
