Description
For the identified 1995–1999 Tahoe and 2006–2010 Hummer H3 rear applications, this silver B8 5100 nitrogen monotube connects through a cross pin above and eyelet below. Length is 16.18 inches compressed or 26.2 inches extended. One shock includes a boot without hardware. The detailed door, spring and drivetrain limits must still be matched.
Vehicle applications
Match the year, model and configuration details shown for the application. Blank fields do not establish compatibility with additional configurations.
| Model years | Vehicle application | Required configuration |
|---|---|---|
| 1995 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive |
| 1995 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive |
| 1996 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil |
| 1996 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar |
| 1996 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil |
| 1996 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil; Submodel: LS |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil; Submodel: LT |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar; Submodel: LS |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 2 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar; Submodel: LT |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil; Submodel: LS |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil; Submodel: LT |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar; Submodel: LS |
| 1997–1999 | Chevrolet Tahoe | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar; Submodel: LT |
| 1997–1999 | Chevrolet Tahoe | Drivetrain: Four Wheel Drive; Front Spring Type: Front Coil; Submodel: Base |
| 1997–1999 | Chevrolet Tahoe | Drivetrain: Four Wheel Drive; Front Spring Type: Front Torsion Bar; Submodel: Base |
| 1995–1997 | GMC Yukon | Body Number Doors: 4 Doors; Drivetrain: Four Wheel Drive |
| 1998–1999 | GMC Yukon | Drivetrain: Four Wheel Drive |
| 2006–2010 | Hummer H3 | |
| 2009–2010 | Hummer H3T |
Specifications
| Type | Nitrogen Gas Charged |
| With Coil Spring | No |
| Internal Design | Monotube |
| Adjustable | No |
| Extended Length (IN) | 26.2 Inch |
| Compressed Length (IN) | 16.18 Inch |
| Upper Mounting Style | Cross Pin |
| Lower Mounting Style | Eyelet |
| Body Color | Silver |
| Quantity | Single |
| Rod Diameter (IN) | 1.81 Inch |
| Valving Type | Self-Adjusting Deflective Disc Valving |
| Rod Finish | Polished |
| Rod Material | Steel |
| Body Material | Steel |
| With Reservoir | No |
| Includes Dust Shield | No |
| Includes Hardware | No |
| Includes Boot | Yes |
| Estimated Install Time (Hours) | 0.5 |
